Inlet Connection: |
8″ ANSI Class 150 Flat Face Flange |
Outlet Connection: |
6″ ANSI Class 150 Flat Face Flange |
Operating Speed Range: |
310 rpm through 760 rpm |
Maximum Allowable Working Pressure: |
80 psig (5.5 barg) |
Maximum Allowable Operating Temp: |
350°F (176°C) |
Shaft Seal: |
Single face mechanical or double bellows |
Bearings: |
Steel cage, Alloy steel rollers and races (no yellow metals) |
Lubrication: |
Once through oil injection system – 9 points (by others) |
Drive Type: |
Direct couple or belt driven, suitable for VFD |
Shaft End: |
3.50″ diameter at coupling |
